鼻内泪囊鼻腔造口术相关结构冠状切面断层解剖学观察

李岩; 马琼杰; 李颖; 李丽明; 耿曼英; 张庆丰; 陈向东

doi:10.13201/j.issn.1001-1781.2019.07.012

鼻内泪囊鼻腔造口术相关结构冠状切面断层解剖学观察

- 1 深圳大学总医院耳鼻咽喉-头颈外科(深圳, 518055);
- 2 郑州大学附属郑州中心医院耳鼻咽喉科;
- 3 郑州大学第二附属医院耳鼻咽喉科
基金项目:
深圳市科技计划项目 (No:JCYJ20170302153015013)

详细信息

通讯作者: 陈向东,E-mail:xdc1981@szu.edu.cn

中图分类号: R762

收稿日期: 2019-05-08

Sectional anatomical observation of coronal plane of dacryocystorhinostomy related structures

- 1 Department of Otolaryngology-Head and Neck Surgery, Shenzhen University General Hospital, Shenzhen, 518055, China;
- 2 Department of Otolaryngology, Zhengzhou Central Hospital Affiliated to Zhengzhou University;
- 3 Department of Otolaryngology, the Second Affiliated Hospital of Zhengzhou University

More Information

Corresponding author: CHEN Xiang-dong, E-mail: xdc1981@szu.edu.cn

Received Date: 08 May 2019

摘要

摘要: 目的:对鼻内泪囊鼻腔造口术相关结构的冠状切面进行断层解剖研究,为临床提供解剖学依据。方法:提取创建的头部冠状切面图像数据集中含泪囊和鼻泪管结构的图像,对左侧泪囊、鼻泪管及毗邻结构的形态、空间相互位置关系进行连续断层解剖学观察,对重要部位微细结构断面进行测量。结果:不同断面的图像可以精准呈现泪囊、鼻泪管和其毗邻结构的原位形态及相互位置关系。泪囊内侧壁最薄1.2 mm,外侧壁最薄0.6 mm,外侧壁内腔面有一高度为2.3 mm的纵行皱襞。膜性鼻泪管内侧壁厚(1.97±0.47) mm,外侧壁厚 (1.52±0.17) mm,膜性管腔横径(1.78±0.12) mm;骨性鼻泪管内侧壁最薄处0.30 mm,外侧壁最薄处0.15 mm,骨性管腔横径(5.50±0.12) mm;膜性管腔截面积与骨性管腔截面积之比为(13.5±2.9)%。结论:高精度冠状位头部切面图像数据集可用于泪囊、鼻泪管及毗邻结构的断层解剖学研究,可用于微细结构的断面解剖学测量。
- 泪囊 /
- 鼻泪管 /
- 断层解剖 /
- 泪囊鼻腔造口术
Abstract: Objective: To study coronal plane of dacryocystorhinostomy related structures for clinical practice. Method: Extracted images concluding lacrimal sac and nasolacrimal canal information from head coronal sectional imaging data-set we created. Observed shape and location of the left lacrimal sac, nasolacrimal canal, and surrounding structures. Measured details of the important portion. Result: Images of different layer show the shape and locative relationship of the lacrimal sac, nasolacrimal canal, and surrounding structures precisely. The thinnest thickness of medial wall and lateral wall of the lacrimal sac is 1.2 mm and 0.6 mm. There is a 2.3 mm high longitudinal fold on the lateral wall. The thickness of medial wall and lateral wall of membranous nasolacrimal canal is(1.97±0.47) mm and(1.52±0.17) mm. Transverse diameter of membranous nasolacrimal canal is(1.78±0.12) mm. The thinnest thickness of medial wall and lateral wall of bony nasolacrimal canal is 0.30 mm and 0.15 mm. Transverse diameter of bony nasolacrimal canal is(5.50±0.12) mm. The proportion of cross-membranous nasolacrimal canal sectional area in bony nasolacrimal canal sectional area is(13.5±2.9)%. Conclusion: Head coronal sectional imaging data-set with high precision can be used for sectional anatomical study of the lacrimal sac, nasolacrimal canal and surrounding structures and measurement of details.
- lacrimal sac /
- nasolacrimal canal /
- sectional anatomy /
- dacryocystorhinostomy

HTML全文

参考文献(6)

[1]	马琼杰, 刘健华, 耿曼英, 等.冠状位头部标本切削冷冻包埋及图像采集技术[J].郑州大学报 (医学版), 2016, 51 (3):364-368.
[2]	ZHANG S W, CHENG Y E, XIE J A, et al.Anatomical study and locating nasolacrimal duct on computed topographic image[J].J Craniofac Surg, 2017, 28:275-279.
[3]	JAÑEZ-GARCIA L, SAENZ-FRANCES F, RAMIREZ-SEBASTIAN J M, et al.Three-dimensional reconstruction of the bony nasolacrimal canal by automated segmentation of computed tomography images[J].PLoS One, 2016, 11:e0155436.
[4]	刘玥, 许建强, 黄杰.鼻背缩窄截骨术中泪道系统的三维重建研究[J].临床耳鼻咽喉头颈外科杂志, 2016, 30 (17):1381-1384.
[5]	ELA A S, CIGDEM K E, KARAGOZ Y, et al.Morphometric measurements of bony nasolacrimal canal in children[J].J Craniofac Surg, 2018, 29:e282-e287.
[6]	CHUNG B S, PARK J S.Real-color volume models made from real-color sectioned images of visible korean[J].J Korean Med Sci, 2019, 34:1-10.
