颈静脉孔区颅底内镜手术解剖

朱杭军; 张建东; 王玉海

doi:10.13201/j.issn.1001-1781.2015.14.015

颈静脉孔区颅底内镜手术解剖

- 1 解放军第101医院耳鼻咽喉科 (江苏无锡, 214044);
- 2 解放军第101医院神经外科
基金项目:
南京军区医学科研课题资助项目(No:11MA013)

详细信息

通讯作者: 张建东,E-mail:101zjd@sina.com

中图分类号: R653

收稿日期: 2015-03-15

Endoscopic anatomy study of jugular foramen region

- 1 Department of Otolaryngology, the 101 Hospital of PLA, Wuxi, 214044, China;
- 2 Department of Neurosurgery, the 101 Hospital of PLA

More Information

Corresponding author: ZHANG Jiandong, E-mail: 101zjd@sina.com

Received Date: 15 March 2015

摘要

摘要: 目的:观测颈静脉孔区解剖结构,并模拟、比较相关内镜手术,为颈静脉孔区颅底内镜手术提供解剖资料。方法:对8例(16侧)成人尸头颈静脉孔区进行解剖,模拟实施迷路后和乙状窦后径路内镜手术,观察手术径路上各结构对手术的影响以及相关血管、神经之间解剖关系。去除顶骨、大脑以及部分小脑组织,暴露颈静脉孔、内耳门及其周围结构,测量颈静脉孔上缘距内耳门下缘垂直距离。结果:8例(16侧)标本均顺利完成迷路后径路模拟内镜手术,仅有2例(4侧)在不损伤小脑情况下顺利完成乙状窦后径路模拟手术,小脑为内镜导入的主要障碍。镜下能清晰分辨颈静脉孔区血管神经区域,舌咽和迷走神经之间间距相对较大,迷走和副神经相距较近,部分小脑下后动脉穿行于其间;舌下神经位于上述颅神经内、下方,形成5~8束较细神经纤维平行分布。颈静脉孔上缘距内耳门下缘垂直距离为(8.26±1.05)mm。结论:相较而言,迷路后径路颈静脉孔区内镜手术术野暴露更好且能更好保护小脑,但其操作相对复杂且对术者要求较高;内耳门仍是手术的可靠定位标志。
- jugular foramen region /
- internal acoustic porus /
- endoscope /
- anatomy
Abstract: Objective: To observe anatomic structure of jugular foramen region by endoscope, to provide anatomic data for avoiding damnification in the surgery.Method: We performed the retrolabyrinthine and retrosigmoid endoscopic surgery on 8 fomalin-fixed adult cadaver specimens and observed the structures of jugular foramen by endoscope and compared the different surgeries at the same time. We excised the calvarium and cereburm and exposured and observed the nerves and vessels. Moreover we measured the the distance from internal accoustic pore to glossopharyngeal and analyse the data by SPSS.Result: All retrolabyrinthine endoscopic surgeries were performed successfully. Only 4 postsigmoid endoscopic surgeries were performed without damage of cerebellum which is the major obstacles. The distance from internal accoustic pore to glossopharyngeal was(8.26±1.05)mm. About half of posterior inferior cerebellar arteries located to inboard of nerves. Conclusion: The jugular foramen region endoscopic surgery can be performed successfully by retrolabyrinthine. The "lockhole" technology by retrosigmoid is more difficult for blocking of cerebella. the internal acoustic porus is a fixed structure of the cerebellopontine angleand a perfect landmark to the surgery.
- jugular foramen region /
- internal acoustic porus /
- endoscope /
- anatomy

HTML全文

参考文献(6)

[1]	KOMUNE N, KOMUNE S, MATSUSHIMA K, et al. Comparison of lateral microsurgical preauricular and anterior endoscopic approaches to the jugular foramen[J]. J Laryngol Otol,2015,129:12-20.
[2]	COLASANTI R, TAILOR AR, GORJIAN M,et al. Microsurgical and endoscopic anatomy of the extended retrosigmoid inframeatal infratemporal approach[J]. Neurosurgery,2015,11:181-189.
[3]	彭志强,徐达传,付万新,等. 内镜辅助下枕下远外侧髁后入路颈静脉孔区的应用解剖[J]. 临床耳鼻咽喉头颈外科杂志,2007,21(23):1078-1080.
[4]	ANICHINI G, EVINS AI, BOERIS D, et al. Three-dimensional endoscope-assisted surgical approach to the foramen magnum and craniovertebral junction:minimizing bone resection with the aid of the endoscope[J]. World Neurosurg, 2014,82:797-805.
[5]	李佩忠,朱杭军.迷路后径路内镜下桥小脑角区手术[J].临床耳鼻咽喉头颈外科杂志,2008,22(22):1009-1010.
[6]	陈合新,钟世镇,徐达传,等.乙状窦后径路骨窗和乳突孔定位的解剖学研究[J]. 中国临床解剖学杂志,2000,18(3):195-196.
