动态腺样体-鼻咽腔比率在OSAHS患儿疾病评估中的应用研究

曾国辉; 李郧; 滕尧树; 朱瑾

doi:10.13201/j.issn.1001-1781.2017.15.008

动态腺样体-鼻咽腔比率在OSAHS患儿疾病评估中的应用研究

- 1. 浙江中医药大学附属杭州第一医院杭州市第一人民医院耳鼻咽喉头颈外科(杭州, 310006);
- 2. 深圳市宝安区福永人民医院耳鼻咽喉头颈外科

详细信息

通讯作者: 朱瑾,E-mail:zhujin2698@163.com

中图分类号: R563.8

收稿日期: 2017-05-07

Clinical application of the dynamic adenoidal-hypertrophy ratio in the evaluation of illness severity in children with OSAHS

- 1. Department of Otorhinolaryngology Head and Neck Surgery, Hangzhou First People's Hospital, Hangzhou, 310006, China;
- 2. Department of Otorhinolaryngology Head and Neck Surgery, Baoan District Fuyong People's Hospital in Shenzhen

More Information

Corresponding author: ZHU Jin, E-mail: zhujin2698@163.com

Received Date: 07 May 2017

摘要

摘要: 目的：通过分析OSAHS患儿不同呼吸时相腺样体-鼻咽腔比率（A/N比率）与睡眠呼吸监测指标的相关性，评估动态A/N比率在OSAHS患儿疾病评估中的应用价值。方法：51例单纯腺样体肥大的OSAHS患儿，利用磁共振结合呼吸门控技术对各呼吸时相（吸气初、中、末及呼气初、中、末）上气道进行动态扫描，并测定A/N比率，分析不同呼吸时相的A/N比率与睡眠呼吸监测指标AHI和LaSO₂的相关性，并通过ROC曲线和Kappa分析分别确定A/N比率在儿童OSAHS病情严重程度评估中的临界值及诊断符合率。结果：OSAHS患儿6个呼吸时相A/N比例均与AHI呈显著正相关（均P<0.01），其中呼气末A/N比率与AHI相关性最高（r=0.559 4）。此外，ROC曲线发现，呼气末A/N比率诊断病情轻-中度及重度的最佳临界值为0.834，两者的符合率分别为81%和84%。结论：通过磁共振结合呼吸门控技术获取动态A/N比率可作为儿童OSAHS诊断的重要影像学手段，且呼气末A/N比率有望成为儿童轻-中度和重度OSAHS的临床影像学分类指标。
- 睡眠呼吸暂停低通气综合征,阻塞性 /
- 睡眠呼吸监测 /
- 腺样体 /
- 核磁共振成像
Abstract: Objective: To evaluate application value of the dynamic adenoidal-hypertrophy (A/N) ratio in children with OSAHS by analyzing the correlation between the A/N ratio at thedifferent respiratory phases and the index of polysomnography.Method: Fifty-one childrens, with simple hypertrophic adenoids, were diagnosed as OSAHS. Magnetic resonance imaging(MRI) with respiratory gating technology were used to scan the upper airway of children during sleep at the early, middle and end phases of respiratory cycle, and measure adenoidal-hypertrophy ratio in different respiratory phases. The correlation analysis was performedbetween the A/N ratio in different respiratory phases and the index of polysomnography(AHI and LaSO₂).Finally, via ROC curve and Kappa analysis, the critical value and diagnosis accordance rate of A/N ratio in illness severity evaluation of children with OSAHS were confirmed.Result: At the 6 respiratory phases,the A/N ratios showed significantly positive correlations with AHI (All P<0.01).There was a highest coefficient between the end-expiratory A/N ratio and AHI(r=0.559 4).In addition, the optimal cut-off point of A/N ratio between slight-moderate and severe OSAHS was 0.834. The diagnosis accuracies of the end-expiratory A/N ratio in severe and slight-moderate OSAHS were 81% and 84%, respectively.Conclusion: MRI with respiratory gating technology obtaining dynamic A/N ratio might be an important method of imaging diagnosis of children OSAHS, and the end expiratory A/N ratio is expected to become a classification index of slight-moderate and severe children OSAHS.
- sleep apnea hypopnea syndrome,obstructive /
- polysomnography /
- adenoid /
- magnetic resonance imaging

HTML全文

参考文献(16)

[1]	WU D, LI X, GUO X, et al.A simple diagnostic scale based on the analysis and screening of clinical parameters in paediatric obstructive sleep apnoea hypopnea syndrome[J].J Laryngol Otol, 2017, 131:363-367.
[2]	JAVED A, KIM Y C, KHOO M C, et al.Dynamic 3-D MR Visualization and Detection of Upper Airway Obstruction During Sleep Using Region-Growing Segmentation[J].IEEE Trans Biomed Eng, 2016, 63:431-437.
[3]	DELROSSO L M.Epidemiology and Diagnosis of Pediatric Obstructive Sleep Apnea[J].Curr Probl Pediatr Adolesc Health Care, 2016, 46:2-6.
[4]	PATINI R, ARRICA M, DI STASIO E, et al.The use of magnetic resonance imaging in the evaluation of upper airway structures in paediatric obstructive sleep apnoea syndrome:a systematic review and meta-analysis[J].Dentomaxillofac Radiol, 2016, 45:20160136.
[5]	SLAATS M, VOS W, VAN HOLSBEKE C, et al Predicting the effect of treatment in paediatric OSA by clinical examination and functional respiratory imaging[J].Pediatr Pulmonol, 2017, 52:799-805.
[6]	中华耳鼻咽喉头颈外科杂志编委会, 中华医学会耳鼻咽喉科学分会.儿童阻塞性睡眠呼吸暂停低通气综合征诊疗指南草案(乌鲁木齐)[J].中华耳鼻咽喉头颈外科杂志, 2007, 42(2):83-84.
[7]	MARCUS C L, BROOKS L J, DRAPER K A, et al.Diagnosis and management of childhood obstructive sleep apnea syndrome[J].Pediatrics, 2012, 130:e714-e755.
[8]	SLAATS M A, VAN HOORENBEECK K, VAN EYCK A, et al.Upper airway imaging in pediatric obstructive sleep apnea syndrome[J].Sleep Med Rev, 2015, 21:59-71.
[9]	WANG Y, MCDONALD J P, LIU Y, et al.Dynamic alterations of the tongue in obstructive sleep apneahypopnea syndrome during sleep:analysis using ultrafast MRI[J].Genet Mol Res, 2014, 13:4552-4563.
[10]	CLARK C, ULUALP S O.Multimodality assessment of upper airway obstruction in children with persistent obstructive sleep apnea after adenotonsillectomy[J].Laryngoscope, 2017, 127:1224-1230.
[11]	TANG X L, YI H L, LUO H P, et al.The application of CT to localize the upper airway obstruction plane in patients with OSAHS[J].Otolaryngol Head Neck Surg, 2012, 147:1148-1153.
[12]	LITMAN R S, SOIN K, SALAM A, et al.Chloral hydrate sedation in term and preterm infrants:an analysis of efficacy and complicatinos[J].Anesth Analg, 2010, 110:739-746.
[13]	王晓川, 洪建国, 杨锡强.异丙嗪使用问题讨论[J].中华儿科杂志, 2010, 48(7):557-558.
[14]	黄洋, 杨磊.多导睡眠监测与A/N值在儿童睡眠呼吸障碍诊治中相关性研究[J].中国实用医药, 2015, 10(2):109-110.
[15]	刘嘉琳, 李庆云, 黄绍光, 等.螺旋CT对OSAHS患者上气道功能的研究[J].上海第二医科大学学报, 2005, 25(5):502-504.
[16]	YUCEL A, UNLU M, HAKTANIR A, et al.Evaluation of the upper airway cross-sectional area changes in different degrees of severity ofobstructive sleep apnea syndrome:cephalometric and dynamic CT study[J].AJNR Am J Neuroradiol, 2005, 26:2624-2629.
